Quick Thermal Outdoor Cabinet Air Conditioner Manufacturing
Company Advantages
· The design of Quick Thermal outdoor cabinet air conditioner follows the market trend, which completely caters to the aesthetic of customers. It also maximizes the overall performance of the product.
· Produced by sophisticated technology, outdoor cabinet air conditioner is of great performance.
· The product has been showing its great market potential since it was launched.
Product Design Feature
1、 Double power supply, reliability greatly improved, especially suitable for telecom outdoor cabinet;
2、 Remote measuring, remote communication, remote control, which can realize multiple automatic protection and comprehensive self-testing function;
3、 Strict process control and international brand parts deployed to ensure high quality and reliable of this product;
4、 Unique energy-saving & control technology;
5、 DC Fan speed PWM control, low acoustic noise during low speed running;
6、Fit for T3 high temperature working condition by using of R134a refrigerant gas;
7、Multiple self-protection design & visible monitoring interface, RS422 / RS485 communication port (MODBUS-RTU protocol);
8、LED Display, all the settings can be changed at the field;
9、 The heating function ;
10、 Dry contact alarm output,NO/NC optional;
11、 Equipped with communication interface: RS422 / RS485 optional.
Product parameter
| Name | Outdoor Cabinet Air Conditioner |
| Model | 8704B TA 030/E/A/H10 |
| Mounting Method | Semi-embedded Mounting |
| AC Power Supply | 220V±15% 50Hz |
| DC Power Supply | 48V±20% |
| Cooling Capacity | 3000W@L35/L35 |
| Cooling Consumption | AC 1020W @L35/L35 |
| DC 200W @L35/L35 | |
| Cooling Capacity | 2330W@L35/L55 |
| Power Consumption | AC 1320W @L35/L55 |
| DC 200W @L35/L55 | |
| Internal Airflow | 850 m³/h |
| Working Temperature Range | -40℃~+55℃ |
| Max Noise Level | 65dB(A) |
| IP Grade | IP55 |
| Net Weight | 27Kg |
| Refrigerant | R134a |
| Dimensions | 1304x504x250(mm, HxWxD) |
| CE&RoHS Compliant | YES |
| Surface Treatment | Outdoor type powder coating, standard color: RAL7035 |
| Heater(Option) | 1000W |
| Heating power consumption | 1100W |
Company Features
· Suzhou Quick Thermal Control Technology Co.,LTD is a company that involves the design, production, and marketing of outdoor cabinet air conditioner. We are highly recognized in the industry.
· We have a technical and skilled highly engaged workforce. They are all perfectionists, with a do or die attitude who holds us all to the highest standard throughout our operations. Our business is supported by a team of professional sales. Along with their years of experience in the outdoor cabinet air conditioner industry, they are able to listen to our customers and respond to their needs in terms of bespoke and niche product ranges.
· In order to fulfill our social and public responsibility, we are committed to solving communities' issues, protecting our environment, and creating benefits to local people. Contact!
Product Details
The details of outdoor cabinet air conditioner are shown for you at below.
Product Comparison
The outdoor cabinet air conditioner produced by Quick Thermal is better than the previous generation. The specific performance is as follows.
Enterprise Advantages
Following the talent strategy, our company recruits people with ability and virtue to build a comprehensive talent team. Our team has excellent academic performance and professional strength.
In order to protect the rights and interests of consumers, Quick Thermal gathers a number of professional customer service staff to solve various problems. It is our commitment to provide quality services.
With the vision to become a company with the most core competitiveness in China, Quick Thermal has always been adhering to the development philosophy of 'honesty and credit, professionalism, concentration, and sci-tech innovation', and the core values of 'unity, cooperation, mutual benefit and win-win'. We try hard to complete the corporate mission of 'winning customers with quality and connecting the world with technology'.
Quick Thermal was founded in After the development for we have become a leader in the industry.
Our company's sales network has not just spread all over the country, but also exported to North America, Europe, Southeast Asia and other countries and regions.
