Reliable Electrical Cabinet Ac Units Electrical Cabinet Ac Units Company
Product details of the electrical cabinet ac units
Product Introduction
Quick Thermal electrical cabinet ac units is designed and made as per the prevailing market norms and guidelines. The product is exmained by a accomplished team to ensure the reliability of functions. The product has been recognized in the industry for its integrity and strength.
Product Design Feature
1、 Remote measuring, remote communication, remote control, which can realize multiple automatic protection and comprehensive self-testing function;
2、 Strict process control and famous brand components to ensure high
quality and reliability of this product;
3、 Fit for harsh condition (T3), R134a refrigerant ;
4、 Multiple self-protection design & visible monitoring interface,
RS485 communication port (MODBUS-RTU protocol);
5、 LED display, all the settings can changed at the field;
6、 The filter net is optional;
7、 Dry contact alarm output,NO/NC optional;
8、 Built in condensed water evaporator.
1、 Modular Design: The product may adopt a
modular design concept, facilitating maintenance and upgrades, ensuring a long
service life and lower operating costs.
2、 Low-Noise Operation: With a low noise
level of 65dB(A), it is suitable for industrial applications that require a
quiet environment, reducing the impact of noise on operators and the
surrounding area.
3、 High Protection Rating: The IP54
protection rating ensures that the air conditioner can withstand dust and water
splashes, making it suitable for use in dusty or humid industrial environments.
4、 Energy-Efficient Performance: Through an
efficient cooling cycle and optimized internal airflow design, the air
conditioner provides stable temperature control while also focusing on energy
efficiency, helping to reduce energy consumption.
5、 Flexible Installation Options: Supports
various installation methods such as side mounting, along with detailed
installation instructions, allowing the product to adapt to different
customers' specific installation requirements and space limitations.
Product parameter
| Name | Indoor Cabinet Air Conditioner |
| Model | TA 030 /S/A |
| Mounting Method | Side Mounting |
| Power Supply | 230VAC±15% 50Hz/60Hz |
| Cooling Capacity | 3000W@L35/L35 |
| Power Consumption | 1300W@L35/L35 |
| Cooling Capacity | 1900W@L35/L55 |
| Power Consumption | 1650W@L35/L55 |
| Internal Airflow | 950 m³/h |
| Working Temperature Range | -40℃~+55℃ |
| Max Noise Level | 65dB(A) |
| IP Grade | IP54 |
| Net Weight | 50Kg |
| Refrigerant | R134a |
| Dimensions | 1150x485x220(mm, HxWxD) |
| CE&RoHS Compliant | YES |
| Surface Treatment | Outdoor type powder coating, standard color: RAL7035 |
| Filter net | Optional |
| Condensed water evaporator | Optional |
