Quick Thermal Outdoor Enclosure Air Conditioner with Custom Services
Product details of the outdoor enclosure air conditioner
Product Description
The production of Quick Thermal outdoor enclosure air conditioner is resource-efficient and causes less pollution to the environment. The skillful QC team guarantees the quality of this product. We are striving hard to provide our clients maximum level of satisfaction with our outdoor enclosure air conditioner.
Product Design Feature
In terms of energy efficiency, the TWA 050 T A adopts advanced frequency conversion technology, equipped with a variable frequency compressor and a speed-regulating fan, which not only enhances the operational efficiency of the equipment but also significantly reduces energy consumption. This design makes the equipment more economical during long-term operation and also reduces the impact on the environment.
In addition, the RS-485 and CAN communication functions of the chiller provide the possibility of real-time remote monitoring for users, increasing the control flexibility of the equipment. Whether it is in a data center that requires precise control or a communication base station with specific remote management needs, the TWA 050 T A can meet these requirements.
The high reliability of the TWA 050 T A means that it can adapt to uninterrupted operation for 7*24 hours, which is crucial for ensuring the continuous operation of critical applications. And its lightweight and compact size make this chiller an ideal choice for mobile applications or small places, such as small data centers, laboratories, or medical facilities.
In summary, the compact design, energy-efficient frequency conversion technology, flexible communication protocol support, and high reliability of the TWA 050 T A air-cooled chiller make it an ideal solution for occasions with limited space but strict requirements for heat dissipation performance.
Product parameter
| Name | Air Cooled Chiler |
| Model | TWA 050/T/A |
| Power Supply | 220V 50Hz |
| Cooling Capacity | 5KW @W18/L35 |
| Cooling Power Consumption | 2.3KW @W18/L35 |
| Max Power Consumption | 3.5KW |
| Max Work Current | 20A |
| Supply water temperature | 18℃ |
| Rated water flow | 2.1m³/h, External Lift: 8m |
| Heater | 2KW |
| Heating Power Consumption | 2.4KW |
| Working Temperature Range | -30℃~+50℃ |
| Max Noise Level | ≤70dB(A) |
| IP Grade | IPX5 |
| Net Weight | 80kg |
| Refrigerant | R410A |
| Dimensions | 245x700x900(mm,HxWxD) |
| CE&RoHS Compliant | YES |
| Surface Treatment | Outerdoor type powder coating, standardcolor: RAL7035 |
| Communication Function | RS 485 MODBUS RTU/CAN |
| Altitude | 0-4000m (Derating by 3%/1000m) |
| Refrigerating medium | 50% Glycol water solution |
Company Advantage
• We have established a professional service team to provide customers with speedy, professional and comprehensive services. Furthermore, we help customers with the grasp of a better understanding and use of products.
• Traffic convenience including easy and open highway access and the great geographic location is conducive to the transportation of Air Condionner,Heat Exchanger,Air Conditonner and Heat Exchangers solutions for industries like telecom,electric power,elevators.
• Quick Thermal's products are sold to major cities in China and exported to countries and regions such as Asia, Europe, and Africa.
• Established in Quick Thermal has gone through ups and downs for years. We embrace today's outstanding achievements among difficulties and hardships, and form our own unique development path.
Want suitable Air Condionner,Heat Exchanger,Air Conditonner and Heat Exchangers solutions for industries like telecom,electric power,elevators? Want creative and satisfactory Air Condionner,Heat Exchanger,Air Conditonner and Heat Exchangers solutions for industries like telecom,electric power,elevators? Quick Thermal is your right choice. Please contact us immediately or leave the contact information, and we will get in touch with you as soon as possible.
