Good Sellingenclosure Air Conditioner
Product details of the enclosure air conditioner
Product Information
The material of Suzhou Quick Thermal Control Technology Co.,LTD will not take any bad effect on people during use. This product has been tested by an independent third party. The accumulation of praises also contribute to the high-quality service of Quick Thermal staff.
Product Design Feature
The robust construction and heavyweight design, with dimensions of 1304x504x300mm and a weight of 80kg, reflect the reliability of this air conditioner as a large-scale cooling solution. An internal airflow of up to 1050m³/h, combined with a low noise level of 65dB(A), achieves a perfect balance between efficient heat dissipation and a quiet environment.
The TA040 E/D model features an outdoor powder coating, with the standard color RAL7035, significantly enhancing its durability in harsh outdoor environments. Moreover, multiple self-protection designs, an LED display, and an RS485 communication interface are equipped, providing users with convenient on-site operation and remote monitoring capabilities.
The main features of this air conditioner include
- High cooling capacity: 4000W cooling capacity to meet the heat dissipation needs of large outdoor equipment.
- Energy-efficient: Adopts energy-saving technology to reduce power consumption without sacrificing cooling performance.
- Long service life: Durable components adapt to harsh outdoor conditions, extending the service life and reducing the need for frequent replacements.
- Outdoor durability: The structural design withstands various weather conditions and is suitable for environments exposed to natural elements.
The 188540 TA040 E/D model is an ideal choice for large outdoor communication base stations, industrial facilities, and other scenarios, providing reliable support for large-scale cooling needs with its high efficiency and low operating costs.
Product parameter
| Name | Outdoor Cabinet Air Conditioner |
| Model | TA 040/E/D |
| Mounting Method | Semi-embedded Mounting |
| Power Supply | -48VDC |
| Cooling Capacity | 4000W@L35/L35 |
| Power Consumption | 1300W@L35/L35 |
| Cooling Capacity | 2450W@L35/L55 |
| Power Consumption | 1750W@L35/L55 |
| Internal Airflow | 1050m³/h |
| Working Temperature Range | -40℃~+55℃ |
| Max Noise Level | 65dB(A) |
| IP Grade | IP55 |
| Net Weight | 80kg |
| Refrigerant | R134a |
| Dimensions | 1304x504x300(mm, HxWxD) |
| CE&RoHS Compliant | YES |
| Surface Treatment | Outdoor type powder coating, standard color: RAL7035 |
Company Feature
• Quick Thermal has established a professional service team which is dedicated to providing quality services for customers.
• Based on the requirements of modern enterprise management system, our company develops ourselves in a long term through forming an experienced talents team.
• Traffic convenience including easy and open highway access and the great geographic location is conducive to the transportation of Air Condionner,Heat Exchanger,Air Conditonner and Heat Exchangers solutions for industries like telecom,electric power,elevators.
• Quick Thermal's high-quality Air Condionner,Heat Exchanger,Air Conditonner and Heat Exchangers solutions for industries like telecom,electric power,elevators are an attraction to domestic and foreign customers.
Hello, if you are interested in Quick Thermal's products, feel free to contact us directly. Don't hesitate, just call us!
