Electrical Cabinet Ac Units - - Quick Thermal
Product details of the electrical cabinet ac units
Product Description
The raw materials of Quick Thermal electrical cabinet ac units are carefully chosen. The production process of these materials are strict and their quality reaches the international standards, which helps it withstand the test of the time. It is checked for its specifications, dimensions, weight, and measurements to ensure the quality. This product can provide customers with more predictable economic benefits.
Product Design Feature
1、 Suitable for temperature control needs in various enclosed areas, such as wireless communication cabinets, battery cabinets, etc
2、 Strict process control and famous brand components to ensure high quality andreliability of this product
3、 Fit for harsh condition (T3), R134a refrigerant
4、 Multiple self-protection design & visible monitoring interface, RS485 communication port (MODBUS-RTU protocol)
5、 LED display, all the settings can changed at the field
6、 The heating function is optional
7、 Dry contact alarm output,NO/NC optional
8、 Anti-theft design, without the protection cover
9、Remote measuring, remote communication, remote control, which can realizemultiple automatic protection and comprehensive self-testing function
Product parameter
| Name | Outdoor Cabinet Air Conditioner |
| Model | TA 030 /E/A/H20 |
| Mounting Method | Semi-embedded Mounting |
| Power Supply | 230VAC±15% 50Hz/60Hz |
| Cooling Capacity | 3000W@L35/L35 |
| Power Consumption | 1430W@L35/L35 |
| Cooling Capacity | 2300W@L35/L55 |
| Power Consumption | 1720W@L35/L55 |
| Internal Airflow | 720 m³/h |
| Working Temperature Range | -40℃~+55℃ |
| Max Noise Level | 65dB(A) |
| IP Grade | IP55 |
| Net Weight | 60Kg |
| Refrigerant | R134a |
| Dimensions | 1350x550x300(mm, HxWxD) |
| CE&RoHS Compliant | YES |
| Surface Treatment | Outdoor type powder coating, standard color: RAL7035 |
| Heater | Optional(2000W) |
| Dehumidity Function | Optional |
Company Feature
• Quick Thermal is located in a beautiful place with well-developed transportation network. This is conducive to the purchase and shipment of goods.
• Quick Thermal has an international sales channel. Air Condionner,Heat Exchanger,Air Conditonner and Heat Exchangers solutions for industries like telecom,electric power,elevators are mainly sold to some countries and regions in Europe, America, and Australia.
• Our company strives to produce high-quality products by establishing a professional production team of high quality. During the production, our team members focus on our own duties and operate efficiently.
If you are interested in Quick Thermal's Air Condionner,Heat Exchanger,Air Conditonner and Heat Exchangers solutions for industries like telecom,electric power,elevators, feel free to contact us.
