Electrical Cabinet Ac Unit by Quick Thermal
Product details of the electrical cabinet ac unit
Product Overview
The variety of electrical cabinet ac unit design sells well all over the world. The product has outstanding performance and stable and reliable quality. Quick Thermal's electrical cabinet ac unit is widely used in various scenes. Quick enjoys market presence and reputation in overseas countries.
Product Introduction
Quick Thermal will show you the specific details of products below.
Product Design Feature
1、Power Supply Compatibility: Supports both 230VAC and 48VDC power supplies, with a voltage fluctuation range of ±15% and a frequency of 50Hz.
2、Wide Operating Temperature Range: Capable of functioning within a temperature range of -40℃ to +55℃.
3、Low Power Consumption: Consumes 1500W at L35/L35 conditions; 900W at L35/L55 conditions.
4、High Protection Rating: IP rating of IP55, providing excellent dust
and water protection.
5、Efficient Airflow: Internal airflow reaches 440m³/h.
6、Installation Flexibility: Supports semi-embedded mounting.
7、Surface Treatment: Features outdoor powder coating in the standard RAL7035 color.
8、External Circulation Function: Equipped with external circulation intake and exhaust air functions for efficient air exchange.
9、Optional Accessories: Offers a 1000W heater as an optional accessory.
Product parameter
| Name | Outdoor Cabinet Air Conditioner |
| Model | TA 015 /E/A/H10 |
| Mounting Method | Semi-embedded Mounting |
| Power Supply | (230VAC&48VDC)±15% 50Hz |
| Cooling Capacity | 1500W@L35/L35 |
| Power Consumption | 870W@L35/L35 |
| Cooling Capacity | 900W@L35/L55 |
| Power Consumption | 1090W@L35/L55 |
| Internal Airflow | 440 m³/h |
| Working Temperature Range | -40℃~+55℃ |
| Max Noise Level | 65dB(A) |
| IP Grade | IP55 |
| Net Weight | 40Kg |
| Refrigerant | R134a |
| Dimensions | 1116x416x170(mm, HxWxD) |
| CE&RoHS Compliant | YES |
| Surface Treatment | Outdoor type powder coating, standard color: RAL7035 |
| Heater | Optional(1000W) |
Company Advantages
Suzhou Quick Thermal Control Technology Co.,LTD is recognized as a preeminent enterprise specialized in producing electrical cabinet ac unit. Suzhou Quick Thermal Control Technology Co.,LTD has set up a production base for electrical cabinet ac unit. Suzhou Quick Thermal Control Technology Co.,LTD always sticks to the principle of customers first. Ask online!
We are responsible for the production of high-quality products, please contact us to order if in need.
