Custom Parts of Air Conditioning System Series
Product details of the parts of air conditioning system
Product Overview
Quick Thermal parts of air conditioning system is engineered using best available raw materials and by implementing latest technologies. It is being improved and updated based on innovative technologies. Quick Thermal's parts of air conditioning system can be used in multiple industries and fields. Since the product was put into the market, it has received good comments from customers.
Product Introduction
Our parts of air conditioning system has the following differentiated advantages compared to similar products.
Product Design Feature
1. Designed with all DC driven components like fans, compressor;
2. Precise temperature control through inverter digital regulation of compressor, fans;
3. Power supply voltage range: DC44~59 V;
4. A comprehensive sell-protection design to realize partial load starting, partial load operation at severe ambient condition;
5. Low power consumption design with EER≥3.5, SEER≥5.5;
6. Energy saving reach to 50% comparing with A.C. version product;
7. IP55 environment protection & fit for T3 high temperature working condition by using of R134a refrigerant gas;
8. The best cooling solution for solar, wind, disel generator etc, hybrid power system;
9. Strict process control and international brand parts deployed to ensure high quality and reliable of this product;
10. Multiple self protection design;
11. LED Display, all the settings can be changed at the field;
12. Dry contact alarm output, NO/NC optional;
13. Equipped with communication interface:RS485.
Product parameter
| Name | Outdoor Cabinet Air Conditioner |
| Model | TA010/E/D |
| Mounting Method | Semi-embedded Mounting |
| Power Supply | -48VDC |
| Cooling Capacity | 1000W@L35/L35 |
| Power Consumption | 280W@L35/L35 |
| Cooling Capacity | 570W@L35/L55 |
| Power Consumption | 400W@L35/L55 |
| Internal Airflow | 400 m³/h |
| Working Temperature Range | -40℃~+55℃ |
| Max Noise Level | 65dB(A) |
| IP Grade | IP55 |
| Net Weight | 27Kg |
| Refrigerant | R134a |
| Dimensions | 797x385x165(mm, HxWxD) |
| CE&RoHS Compliant | YES |
| Surface Treatment | Outdoor type powder coating, standard color: RAL7035 |
| Heater(Option) | DC300W |
Company Introduction
As a modern enterprise, Suzhou Quick Thermal Control Technology Co.,LTD focuses on independent R&D, mass production and marketing. Air Condionner,Heat Exchanger,Air Conditonner and Heat Exchangers solutions for industries like telecom,electric power,elevators are key products. We uphold the business philosophy of 'pursuing excellent quality and satisfying customer's needs', and we carry forward the enterprise spirit of 'based on honesty, change by innovation, cooperate for mutual benefit'. Under the guidance of market, we strive to improve brand awareness and reputation through technology. Besides, we continuous develop and provide customers with high-quality products and comprehensive services. With a focus on talents, our company cultivates a group of high-quality and high-level professional talents. They are the internal motivation for the long-term development. With a focus on customers, Quick Thermal analyzes problems from the perspective of customers and provides comprehensive, professional and excellent solutions.
We are waiting for consulting from new and old customers!
