Custom Cabinet Air Conditioners Factory Direct Supply
Product details of the cabinet air conditioners
Quick Detail
Quick Thermal cabinet air conditioners effortlessly strikes the perfect balance between practicality and beauty. The product has passed the quality and performance tests conducted by the third party assigned by the clients. The cabinet air conditioners produced by Quick Thermal is widely used in industry. Suzhou Quick Thermal Control Technology Co.,LTD can offer free replacement service if damage caused during transportation.
Product Introduction
The details of cabinet air conditioners are presented to you in the following section.
Product Design Feature
Product parameter
| Model/Spec | 3.5kw | 5.0kw | 7.5kw | 12.5kw |
| Model | TAR 0004 | TAR 0005 | TAR 0008 | TAR 0013 |
| Function | Cooling + heating/constant temperature and humidity | |||
| 760 Depth (W×D×H)(mm) | 443×715×218 | 443×715×218 | 443×715×351 | 443×715×440 |
| Function | Cooling + heating | |||
| 400 Depth (W×D×H)(mm) | 444×395×352 | 444×395×352 | 444×395×529 | / |
| Max Cooling Capacity (kW) | 3.5 | 5 | 7.5 | 12.5 |
| Air Flow (m³/h ) | 800 | 1100 | 1650 | 2200 |
| Max Operating Current (A) | 11.5 | 16.5 | 20 | 35 |
| Power Supply | 220V1Ph/50Hz | |||
| Heater (kW） | 1 | 1 | 1 | 2 |
| Humidification (kg/h) | 1 | 1 | 1.5 | 3 |
| Dimensions (W×D×H)(mm) | 794×310×537 | 794×310×537 | 1045 ×431×760 | 1045 ×431 ×1375 |
| Indoor unit weight for 760mm depth (kg) | 27 | 28 | 36 | 42 |
| Indoor unit weight for 400mm depth (kg) | 25 | 26 | 36 | / |
| Outdoor unit weight ( kg ) | 30 | 34 | 60 | 85 |
| Strong drainage components | Standard | |||
| Low-temperature start-up components | Optional | |||
Company Introduction
After years of development, Quick Thermal has developed into a leading company in the cabinet air conditioners market. Covering a large scale, the factory owns 50% of highly automatic production lines. With space combining with technologies, we can flexibly arrange the production lines to coordinate the production demands. We sincerely expect a cooperation with domestic and foreign businesses to achieve win-win. Get quote!
We have strong strength and rich experience. And we are looking forward to discussing business cooperation with partners from all walks of life!
